| SYSTEM |
| Main Processor |
ARM Processor |
| Operating System |
Embedded LINUX |
| Onvif Compliance |
Onvif Profile S |
| User Management |
User level: administrator, regular user |
| Log |
System, Recording, User |
| Date & Time |
Time Zone, Manual, Automatic Sync NTP, Daylight Saving Time |
| Fan |
No |
| Security |
Encrypted streaming & control |
| VIDEO |
| Inputs |
4 channels |
| AUDIO |
| Audio Input/Output |
3.5 mm Line in x1
3.5 mm Line out x1 |
| Two-way Communication |
Supported |
| Audio Format |
G.711 |
| DISPLAY |
| Interface |
HDMI x 1 (4K Max), VGA x1 (1080P) |
| Resolution |
3840 x 2160, 1920 x 1080, 1280 x 1024,1024 x 768 |
| Display Split |
1 x 1, 2 x 2, customs |
| OSD |
Time OSD, channel OSD |
| Stream Application |
1x1: 1ch 4K MAX 2x2: 2MP in, 4x1080P 2x2: >2MP,Camera Stream 2
3x3: and above: Camera Stream 2 |
| PTZ Operation |
Direction control, home,iris, preset, patrol |
| VIDEO DETECTION AND ALARMS |
| Event |
Camera: Camera Alarm In, Motion detection, Camera disconnection,Tampering detection, Smart motion detection, intrusion, Crowd detection, multi-loitering System: System Alarm in/out, Disk failure, Disk full |
| Event Action |
Video recording, Send email, Buzzer, FTP, Camera Alarm Out, PTZ-Preset, System Alarm Out,Send video to full screen |
| Alarm Input |
4 |
| Alarm Out |
1 |
| RECORDING |
| Compression |
H.265 HEVC smart codec/H.264 |
| Resolution |
Up to 3840 x 2160 |
| Frame Rate |
30 fps |
| Recording Mode |
Continuous, Manual, Event |
| Max Pre-Event Recording Buffer Size |
Main Stream: 10Mb Sub Stream: 6Mb |
| Post-Event Recording Interval |
30 s (Max. 60 s) |
| Recording Stream |
Support main stream and sub stream simultaneous recording |
| Recording Throughput |
64 Mb |
| STORAGE |
| Internal HDD |
Internal x1 (3.5) |
| HDD Max. Capacity |
10 TB |
| Manual Backup |
USB Dongle (FAT Format) |
| PLAYBACK AND BACKUP |
| Sync Playback |
4 channels |
| Decoding |
H.265/H.264: 3840X2160 @ 30 fps (1-CH), 2560*1920 @30fps(1-CH), 1920X1080 @ 120 fps (4-CH) |
| Search Mode |
Time search ,Event Search, Video clip |
| Playback Function |
Regular (play, pause, stop), play backwards, next frame, Go back 30 seconds, Go forward 30 seconds ,speed control, timeline, timeline scale,Digital zoom,snapshot,back up |
| Snapshot |
JPEG |
| ENVIRONMENTAL |
| Operating Temperature |
-10°C ~ 55°C (14°F ~ 131°F) |
| Relative Humidity |
Less than 90% RH |
| Storage Temperature |
–40°C ~ 60°C (-40°F ~ 140°F) |
| ELECTRICAL |
| Power Supply |
100-240V AC, 50/60 Hz |
| Power Consumption |
Max. 65 W; |
| NETWORK |
| Ethernet |
10/100Mbps Ethernet (RJ-45) x 1 |
| PoE |
802.3at/af compliant PoE ports x 4 |
| Supported Protocols |
IPv4, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/ RTCP, SMTP, FTP, DHCP, NTP, DNS, DDNS, IP
Filter, P2P |
| Maximum Number of Users |
16 |
| Network Throughput |
64 Mb |
| Smart Phone Compatibility |
IOS 11 or later and Android 5.0 or later support |
| Browsers |
Edge, Chrome, Firefox, Safari |
| AUXILIARY INTERFACE |
| USB Ports |
Front x2, usb 2.0; Back x1, usb 2.0 |
| PHYSICAL |
| Dimensions |
255.0 × 237.3 × 45.3 mm (10.04 × 9.34 × 1.78 inch) |
| Weight (Without HDD) |
1 kg (2.20 lb) without HDD |
| REGULATORY |
| Emissions |
FCC Part 15, CE (EN 55032, EN 61000-3-2, EN 61000-3-3, EN 61000-
6-4),
ICES-003, Comply with UKCA and RCM |
| Immunity |
CE(EN 50130-4, EN 55024, EN 55035) Comply with UKCA and RCM |
| Safety |
UL LISTED TO UL/CSA 62368-1, CE(EN 62368-1), Comply with UKCA and RCM |
| RoHS |
CE(EN 63000), UAE(Cabinet Decree No.10 of 2017) |
| RECOMMENDED CAMERAS |
| Fixed Dome Cameras |
HC35W43R3, HC35W45R3, HC35W48R3 |
| MFZ Dome Camera |
HC35W43R2, HC35W45R2, HC35W48R2 |
| Fixed Bullet Camera |
HC35WB3R3, HC35WB5R3, HC35WB8R3 |
| MFZ Bullet Camera |
HC35WB3R2, HC35WB5R2, HC35WB8R2 |
| Fixed Ball Camera |
HC35WE3R3, HC35WE5R3, HC35WE8R3 |
| MFZ Ball Camera |
HC35WE3R2, HC35WE5R2, HC35WE8R2 |
| Fixed Micro Dome Camera |
HC35W25R3 |
| Speed Dome Camera |
HC35WZ2R25, HC35WZ5R30 |
|
