State-of-the-art technology from a global security industry leader
Easy to install, operate and maintain, the IP-AK2 requires no software installation. Simply connect a TCP/IP network cable from IP-AK2 control panel to a computer and use standard web browser (Internet Explorer, Firefox, etc( for reliable and remote access control. This 2-door controller is expandable up to 20 doors over an RS485 network. It supports up to 10,000 cardholders, and has a transaction storage capacity of up to 25,000 alarms and events. Built-in support for visualised door status viewing provides operators a complete picture of each device as well as easy, real-time manual control of locks and other devices.
IP-AK2
Access Control Solution
The new generation Honeywell lP-AK2 is 2-door web-based access control panel designed to provide easy-to-use and cost-effective solution to meet the requirements of all entry-level applications. The system's built-in web server allows users to use a standard Web browser to manage, control, and monitor the access control system from anywhere an Internet connection is available. This brings users with simplicity, flexibility, and cost-effectiveness without sacrificing the performance of access control.
FEATURES
- "Complete system configuration from Web Interface
- Powerful 32-bit processor and built-in SOL Lite database for fast, reliable processing
- Two-door interlock supported
- Onboard I/0: 2 readers, 8 supervised inputs, 4 relay outputs
- Flash programming for firmware revision updates
- Database and configuration archiving support
- Anti-passback capability, hard and soft
- Real-time clock, live event and alarm monitoring
- Card format compatibility: 128 types of Wiegand format support
- Specifications
- Ordering Info
- Resources
Specifications
System Overview
- 2-doors controller, expandable up to 20 doors over RS485 network
- Embedded Web server
- 32-bit ARM9 processor
- Onboard 1/0: 2 readers; 8 supervised inputs; and 4 relay outputs
- Flash programming for firmware revision updates
- Anti-passback capability, hard and soft
- Two-door interlock supported
- Real time clock
System Capacities
- Cardholders: 10,000
- Transaction storage: 25,000 alarms and events
- 127 -nme Zones and 255 Holidays
- 128 Access Level
- Card format compatibility: 128 typess
of Wiegand format support
- Credential facility codes: 8
Database and Database Maintenance
- Built-in SOL Lite Database
- Manual backup of system database to local client PC
- Alarm & Event database auto backup
Communication
- Onboard Ethernet port connected to TCP/IP network as master panel
- Onboard RS485 connection for downstream panels
Certification and Approvals
Web Brower
- Standard web browser e.g. Internet Explore or Firefox
- Complete system configuration from Web Interface
- Live event and alarm monitoring
- Visualized viewing of door status and real-time manual control of locks and other devices
Card report
- Alarm & Event report
- Detailed report generator
- 128-bit SSL browser login encryption
- Up to 6 users to log in simultaneously
Language
- Multi-languages supported
- Currently available in English, Simplified Chinese, Traditional Chinese, and Korean
Dimensions
- Boards: 152mm W x 229mm H
- Enclosure: 340mm H X 290mm W X 78mm D
Power Requirements
- Power Supply: 220VAC (11 0VAC) to 12 VDC transformer
- Battery Backup: 12 VDC, 3.2 AHr sealed lead-acid battery
Environment
- Temperature: 0°C to 50°C for operating, -55°C to +85°C for storage
- Humidity: 5% to 85% RHNC
| Model No. |
IP-AK2 |
| IP-AK2 |
IP-AK2 Control Panel only |
| DMCH01186579 |
Universal Cabinet for one PCB of IP-AK2 DOES NOT INCLUDE PSU |
| PSU-12RDC2-BCDUPS |
Power Supply 12V DC , 2.5 Amp ( 1.5 A Load current , 1 A Battery Charging Current with UPS feature , only to be used each with DMCH01186579) |
