| OPERATIONAL |
|
| Video Standard |
NTSC/PAL |
| Scanning System |
Progressive |
| Image Sensor |
1/1.8” CMOS |
| Number Of Pixels (H x V) |
8MP (3840 x 2160) |
| Minimum Illumination (Color/BW) |
0.006Lux @F1.4(AGC on); BW: 0lux (IR on) |
| S/N Ratio |
>50dB |
| Electronic Shutter Speed |
1/3 ~ 1/100,000 |
| IR Distance |
60M |
| IR Light Control |
Smart IR (Auto/Manual)/OFF |
| Removable IR-Cut Filter |
Yes |
| Day/Night |
Auto/Day/Night/Timing |
| Backlight Compensation |
WDR, HLC, BLC |
| White Balance |
Auto/Indoor/Outdoor/Manual |
| Gain Control |
0 ~ 100 % |
| Wide Dynamic Range |
120dB |
| Noise Reduction |
3D DNR |
| Lens |
2.8~12mm, DC-Iris |
| Digital Image Stabilization |
Yes |
| Angle Of View (H x V) |
H:108°~45.5°, V:58°~25.5° |
| Privacy Masking |
Off / On (4 Areas) |
| Defog |
Yes |
| Local Storage |
Micro SD/SDHC/SDXC card slot (256 GB) |
| Alarm Inputs/Outputs |
1 in/1 out |
| Reset |
Supported |
| VIDEO |
|
| Video Compression |
H.265/H.264/MJPEG |
| Resolution |
8MP (3840 × 2160), 6MP (3072 × 2048), 5MP (2592 × 1944), 4MP (2592 × 1520), 2K (2560 × 1440), 3MP (2304 × 1296), 1080P (1920 × 1080), 720P (1280 × 720), D1 (720 × 576), VGA (640 × 480), 480 × 240, CIF (352 × 288) |
| Number of Video Streams |
3 |
| Frame Rate* |
Main Stream: 8MP/6MP/5MP/4MP/2K/3MP/1080P 25/30fps
Second Stream: 1080P/720P/D1/VGA/CIF 25/30fps
Third Stream: D1/VGA/CIF/480×240 25/30fps |
| Bit Rate* |
64 K ~ 12 Mbps |
| AUDIO |
|
| Audio Compression |
G.711a/G.711Mu |
| Audio Stream |
Full duplex |
| Audio Interface |
Line in/out |
| NETWORK |
|
| Ethernet |
10 Base-T/100 Base-TX Ethernet (RJ-45) |
| Supported Web Browsers |
Microsoft Edge, Chrome |
| Supported OS |
Microsoft Windows 10, Windows 11 |
| Protocols** |
IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, DHCP, NTP, FTP, DNS, DDNS, QoS, SNMP, 802.1X, UDP, ICMP, ARP, TLS |
| Interoperability |
ONVIF Profile G/S/T/M |
| Maximum Users Access |
10 Users |
| Security |
Firmware encrypted, User account and password protection, HTTPS, IP Filter, Digest authentication, TLS1.2 only, AES128/256, SSH/Telnet closed |
| EVENTS / ANALYTICS |
|
| Video Analytics |
Standard: Motion detection, Scene change, Video Blurr
AI Based: Smart motion, Intrusion, Line crossing detection, Unattended object detection, Missing object detection, Face Detection |
| Event Type |
Analytics alarm, Security alarm, Disk alarm, Recording alarm |
| Event Linkage |
Email, Push notification, SD card recording, Digital output |
| Event |
Event notification using digital output SMTP, MicroSD card |
| ELECTRICAL |
|
| Power Supply |
DC12V, PoE (IEEE 802.3af)(Class 0) |
| Power Consumption (Max) |
12W |
| MECHANICAL |
|
| Dimensions |
278.3 x 100.2 x 88.7 mm (10.96” x 3.94” x 3.49”) |
| Product Weight |
1.04 kg (2.29 lb) |
| Body Material |
Aluminium alloy |
| Color |
White (RAL9003) |
| ENVIRONMENTAL |
|
| Operating Temperature |
-40 °C ~ 60 °C (-40 °F ~ 140 °F) |
| Relative Humidity |
Less than 95%, Non-condensing |
| Ingress Protection |
IP66, IP67 |
| Impact Resistance |
IK10 |
| REGULATORY |
|
| Emissions |
FCC PART 15, CE (EN 55032) |
| Immunity |
CE (EN 55035) |
| Safety |
UL 62368-1 |
| RoHS |
IEC 62321-3-1, IEC 62321-5, IEC 62321-4, IEC 62321-6, IEC 62321-7-1, IEC 62321-7-2, IEC 62321-8 |
| Country Origin |
India |
| SYSTEM COMPATIBILITY |
|
| Pro-Watch NVR |
Up to 256 IP channels RAID5/6 enterprise NVR |
| MAXPRO NVR PE |
Up to 128 IP channels RAID5/6 enterprise NVR |
| MAXPRO NVR SE |
Up to 64 IP channels system NVR |
| MAXPRO NVR XE |
Up to 16 IP channels system NVR |
| MAXPRO NVR Software |
Up to 128 IP channels recording software |
| MAXPRO CE |
Up to 256 IP channels RAID5/6 |
|
