| specification_description |
| OPERATIONAL |
|
| RAM |
1 GB |
| Flash |
512 MB |
| Video Standard |
NTSC/PAL |
| Scanning System |
Progressive |
| Image Sensor |
1/2.8” CMOS |
| Sensor Size (H x V) |
5.216 x 3.928 mm |
| Number of Pixels (H x V) |
2MP (1920 x 1080) |
| Minimum Illumination (Color/BW) |
Color: 0.002Lux @ F1.6
BW: 0lux @ F1.6 (IR on) |
| S/N Ratio |
> 55 dB |
| Electronic Shutter Speed |
1/3 ~ 1/100,000 |
| IR Distance |
50 m |
| IR Light Control |
Smart IR (Auto/Manual)/OFF |
| IR Light Number |
4 |
| Removable IR-Cut Filter |
Yes |
| Day/Night |
Auto/Day/Night/Timing |
| Backlight Compensation |
WDR, HLC, BLC |
| White Balance |
Auto/Tungsten/Fluorescent/Daylight/Shadow |
| Gain Control |
0 ~ 100% |
| Wide Dynamic Range |
140 dB |
| Noise Reduction |
3D DNR |
| Lens |
2.7 ~ 13.5 mm, DC-Iris, F1.4 ~ F2.8 |
| Digital Image Stabilization |
Yes |
| Angle of View (H x V) |
H: 94.47° ~ 30.9° V: 52.48° ~ 18.09° |
| Privacy Masking |
Off / On (4 Areas) |
| Defog |
Yes |
| Encryption Chipset |
Hardware embedded |
| Local Storage |
Micro SD/SDHC/SDXC card slot (1TB) |
| Alarm Inputs/Outputs |
2 in/1 out |
| Reset |
Supported |
| VIDEO |
|
| Video Compression |
H.265/H.264/MJPEG, Smart codec |
| Resolution (16/9) |
1920 x 1080/1280 x 720 |
| Resolution (4/3) |
640 x 480/320 x 240 |
| Number of Video Streams |
3 |
| Frame Rate |
Main Stream:
1920x1080 50/60fps, 1280x720 25/30fps
Second Stream: 1920x1080/704 x 576 (PAL)/704 x 480 (NTSC)/640 x 480/352 x 288 (PAL)/352 x 240 (NTSC) 25/30fps
Third Stream: 640 x 480/352 x 288 (PAL)/352 x 240 (NTSC)/320 x 240 25/30fps |
| Bit Rate |
100 K ~ 12 Mbps |
| Analog Output Support |
CVBS |
| PTZ |
|
| Pan Range |
0° ~ 355° (-177.5° ~ 177.5°) |
| Tilt Range |
0° ~ 75° |
| Rotation Range |
0° ~ 354° (-163° ~ 191°) |
| AUDIO |
|
| Audio Compression |
G.711 a/G.711 Mu |
| Audio Stream |
Full duplex |
| Audio Interface |
Line in/out, Built-in Mic |
| NETWORK |
|
| Ethernet |
10 Base-T/100 Base-TX Ethernet (RJ-45) |
| Supported Web Browsers |
Microsoft Edge, Chrome |
| Supported OS |
Microsoft Windows 10, Windows 11 |
| Protocols* |
IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, DHCP, NTP, DNS, DDNS, QoS, SNMP, 802.1X, UDP, ICMP, ARP, TLS |
| Interoperability |
ONVIF Profile G/S/T/M |
| Maximum Users Access |
10 Users |
| Security |
Software: Firmware encrypted&Signed, SD card encryption, User account and password protection, HTTPS, IP Filter, Digest authentication, TLS1.2 only, Stream encryption, AES128/256, SSH/Telnet closed, PCIDSS compliance & attestation Hardware: Secure boot, Secure authentication chipset built-in |
| Languages Supported |
Arabic, Chinese (Traditional), Czech, Dutch, English, French, German, Italian, Japanese, Korean, Polish, Portuguese (Brazil), Russian, Spanish, Turkish |
| EVENTS/ANALYTICS |
|
| Video Analytics |
Standard: Motion detection, Scene change
AI Based: Smart motion, Intrusion, Multi loitering, People counter, Face detection, Line crossing detection, Unattended object detection, Missing object detection |
| Event Type |
Analytics alarm, Security alarm, Disk alarm, Recording alarm, Audio detection |
| Event Linkage |
Email, Push notification, SD card recording, Digital output |
| Region of Interest |
8 |
| Event Notification |
Event notification using digital output, SMTP, FTP, MicroSD card |
| ELECTRICAL |
|
| Power Supply |
AC24V, DC12V, PoE (IEEE 802.3af)(Class 0) |
| Power Consumption (Max) |
7.56 W |
| MECHANICAL |
|
| Dimensions |
Ø126.0 mm x 124.0 mm (Ø4.96” x 4.88”) |
| Dome Diameter |
Ø96.40 mm (3.80”) |
| Product Weight |
0.60 kg (1.32 Ib) |
| Package Weight |
0.80 kg (1.76 Ib) |
| Body Material |
Plastic |
| Color |
White (RAL9003) |
| ENVIRONMENTAL |
|
| Operating Temperature |
Starting Temperature: 0 °C ~ 50 °C (32 °F ~ 122 °F)
Working Temperature: -10 °C ~ 50 °C (14°F ~ 122 °F) (IR off) |
| Relative Humidity |
Less than 90 %, Non-condensing |
| Impact Resistance |
IK10 (Bubble only) |
| REGULATORY |
|
| Emissions |
FCC PART 15, CE (EN 55032), ICES-003, Complies with RCM and UKCA |
| Immunity |
CE (EN 50130-4, EN 55035), Complies with RCM and UKCA |
| Safety |
UL listed to UL/CSA 62368-1, CE (EN 62368-1), Complies with RCM and UKCA |
| RoHS |
CE (EN 63000), UAE (Cabinet Decree No.10 of 2017) |
| Country of Origin |
India |
|
